It features unique and advanced merits with compact size, high burning effect, reasonable burning technology, high degree of non-harm etc.It is an ideal choice for waste treatment of hospitals, hotels and various areas.
Features:
(1) Gasifiedpyrolysis incineration is used for burning many kinds of waste. (2) Waste can be burned once everyday by gasified incineration. (3) Gasified incineration, mixed incineration and burnout treatment ensures low emission standard of dust,dioxin etc. (4) Totally enclosed operation is suitable for treating infectious waste to avoid secondary pollution. (5) Compact structure and small land occupation. WWW.HICLOVER.COM｜Waste Incinerators ｜Auto Roll Air Filters
Nanjing Clover Medical Technology Co.,Ltd.
Tel: +86-25-8461 0201 Mobile: +86-13813931455(whatsapp/wechat) Website: www.hiclover.com Email: sales@hiclover.com Email: hicloversales@gmail.com

Items/ModelTS10(PLC)TS20(PLC)TS30(PLC)TS50(PLC)TS100(PLC) Burn Rate (Average)10 kg/hour20 kg/hour30 kg/hour50 kg/hour100 kg/hour Feed Capacity(Average)20kg40kg60kg100kg200 kg Control ModePLCPLCPLCPLCPLC Combustion Chamber100L210L330L560L1200L Internal Dimensions50x50x40cm65x65x50cm75x75x60cm100x80x70cm120x100x100cm Secondary Chamber50L110L180L280L600L Smoke Filter ChamberYesYesYesYesYes Feed ModeManualManualManualManualManual Voltage220V220V220V220V220V Power0.5Kw0.5Kw0.5Kw0.7Kw0.7Kw Oil Consumption (kg/hour)5.4–12.67.8–16.310.2–2012.1–2414–28 Gas Consumption (m3/hour)6.2–11.48–15.79.8–209.9–26.110–32.2 Temperature MonitorYesYesYesYesYes Temperature ProtectionYesYesYesYesYes Oil Tank100L100L100L100L200L Feed Door30x30cm45x40cm55x50cm70x55cm80x60cm Chimney3Meter3Meter5Meter5Meter10Meter Chimney TypeStainless SteelStainless SteelStainless SteelStainless SteelStainless Steel 1st. Chamber Temperature800℃–1000℃800℃–1000℃800℃–1000℃800℃–1000℃800℃–1000℃ 2nd. Chamber Temperature1000℃-1200℃1000℃-1200℃1000℃-1200℃1000℃-1200℃1000℃-1200℃ Residency Time2.0 Sec.2.0 Sec.2.0 Sec.2.0 Sec.2.0 Sec. Gross Weight1500kg2200kg3000kg4500kg6000kg External Dimensions140x90x120cm160x110x130cm175x120x140cm230x130x155cm260x150x180cm A mechanical particulate collector must be incorporated after secondary combustion chamber for removal of particulate pollutants entrained in the flue gas stream. The particulate collectors may include any of the following or a combination Overall plant layout Feed chamber/charging Primary combustion chamber Particulate scrubbers Acid gas scrubbers. The stack/chimney. Minimum capacity of primary chamber = 0.10cubic meters Burn rate (rate of waste incineration) = 10 kg per hour Should have a full width counterbalance loading door allowing easy access to the main chamber for loading and removing ash. Controlled hygienic mechanical feeding that does not negatively influence the air temperature in the primary and secondary chambers of the incinerator shall be used.This chamber should be equipped with burners that use low sulphur fuel. The chamber should ensure a minimum exit temperature of 850 degrees centigrade. This unit should operate at over 1100 deg C to ensure complete combustion. This chamber should be equipped with burners that use low sulphur fuel. Heavy-duty steel casing High quality refractory lining and insulation Large full size top load door and liquid retention sill. 1 x oil fired ignition burners operated on/off Combustion efficiency (C.E) shall be at least 99.00% where C.E = %Carbon dioxide x 100 / [% Carbon dioxide + carbon monoxide] The temperature of the primary chamber shall be 800 +/- 50 degrees centigrade The secondary chamber gas residence time shall be at least 1 second at 1050 +/- 50 degrees centigrade with 3% oxygen in the stack gas. Opacity of the smoke must not exceed 20% viewed from 50 metres with naked eyes. All the emission to the air other than steam or water vapour must be odourless and free of mist, fume and droplets. A 99.99% destruction and removal efficiency (DRE) for each principal organic hazardous constituent (POHC) in the waste feed where DRE [ ( Win – Wout) /Win ] x 100 where Win = mass feed rate of the POHC in the waste stream fed to incinerator and Wout = mass emission rate of POHC in the stack prior to the release to the atmosphere. The average dioxin and furan concentration in the emission should not exceed 80mg/m3 total dioxins and furans if measured for a period of 6 to 16 hours.
